Resumen de caracterísiticas
Juegos de conectores
Kit ciego
Hembra
Poliamida (PA)
Negro
Fundición de aluminio, Resistente a la corrosión
Grado de protección: IP67 / IP69
Detalles del producto
Identification
- Category 连接器组
- Series HARTING UIC
- Identification UIC IT
- Element 连接器组
- Specification 盲孔套件
Version
- Gender 母头
Technical characteristics
- Insulation resistance >107 Ω
- Tightening torque 5 Nm M6固定螺栓
- Limiting temperature -40 ... +90 °C
- Mating cycles ≥ 10,000
- Degree of protection acc. to IEC 60529 IP67 / IP69
Material properties
- Material (insert) 聚酰胺 (PA)
- Colour (insert) 黑色
-
Material (hood/housing)
压铸铝防腐蚀
- Surface (hood/housing) 粉末涂层
- Colour (hood/housing) RAL 2004（纯橙色）
- Material (seal) 硅酮
- Material (locking) 不锈钢
- Material flammability class acc. to UL 94 V-0
- RoHS 符合
- ELV status 符合
- China RoHS e
- REACH Annex XVII substances 不包含
- REACH ANNEX XIV substances 不包含
- REACH SVHC substances 不包含
- California Proposition 65 substances 不包含
Specifications and approvals
-
Specifications
灵感来自 UIC 50558灵感来自 IRS 50558IEC 61373 2类IEC 60529
Commercial data
- Packaging size 1
- Net weight 0.657 kg
- Country of origin 印度
- European customs tariff number 85366990
- eCl@ss 27440115 Circular connector (set)
- ETIM EC002635
- UNSPSC 24.0 39121413
