Resumen de caracterísiticas
Cable de cobre (redondo)
Resistente al aceite
12x 0,34 mm²
PVC
Detalles del producto
Identification
- Category Cableado de sistema
- Element Cables a granel
- Specification No montado
- Type of cable Cable de cobre (redondo)
- Description of the cable Resistente al aceite
Version
- Number of cores 12
- Core structure 12x 0,34 mm²
- Shielding No blindado
Technical characteristics
-
Limiting temperature
-40 ... +80 °C no desplazado-5 ... +80 °C movido
- Cable diameter 7,8 mm
-
Minimum bending radius
4x diámetro de cable (plegado único)7,5x diámetro de cable (plegado repetido)
- Insulation resistance @ 20 °C ≥ 20 MΩ x km
Material properties
- Material (cable) PVC
- Colour (cable) Gris
Specifications and approvals
-
Specifications
VDE 0482-332-1-2IEC 60332-1-2IEC 60332-1VDE 0472
Commercial data
- Packaging size 1
- Net weight 127 g
- Net weight 102 g/m
- Country of origin Alemania
- European customs tariff number 85444995
- eCl@ss 27061801 Data and communication cable (copper)
- ETIM EC003249
- UNSPSC 24.0 26121609
