Resumen de caracterísiticas
Aislantes
Push-In
Macho
Policarbonato (PC)
RAL 7032 (gris guijarro)
Corriente nominal: 16 A
Tamaño: 3 A
Contactos: 5
Sección de conductor: 0.5 ... 2.5 mm²
Aleación de cobre
Chapado en plata
Detalles del producto
Identification
- Category Inserts
- Series Han® Q
- Identification 5/0
Version
- Termination method Push-In
- Gender Male
- Size 3 A
- Number of contacts 5
- PE contact Yes
Technical characteristics
- Conductor cross-section 0.5 ... 2.5 mm²
- Rated current 16 A
- Rated voltage conductor-earth 230 V
- Rated voltage conductor-conductor 400 V
- Rated impulse voltage 4 kV
- Pollution degree 3
- Insulation resistance >1010 Ω
- Limiting temperature -40 ... +125 °C
- Mating cycles ≥ 500
Material properties
- Material (insert) Polycarbonate (PC)
- Colour (insert) RAL 7032 (pebble grey)
- Material (contacts) Copper alloy
- Surface (contacts) Silver plated
- Material flammability class acc. to UL 94 V-0
- RoHS compliant
- ELV status compliant
- China RoHS e
- REACH Annex XVII substances Not contained
- REACH ANNEX XIV substances Not contained
- REACH SVHC substances Not contained
- California Proposition 65 substances Not contained
Specifications and approvals
-
Specifications
IEC 60664-1IEC 61984
Commercial data
- Packaging size 10
- Net weight 18 g
- Country of origin Germany
- European customs tariff number 85389099
- GTIN 5713140448476
- eCl@ss 27440205 Contact insert for industrial connectors
- UNSPSC 24.0 39121522
