Resumen de caracterísiticas
Macho
Contactos: 2
Tamaño: 1 A
Poliamida (PA)
RAL 9005 (negro intenso)
Detalles del producto
Identification
- Category Aislantes
- Series Han® 1A
- Features Suitable for LC contacts
Version
- Gender Macho
- Size 1 A
- Number of contacts 2
- Locking type Enclave único
-
Details
Por favor, pida el enclavamiento por separado.Pida por separado las capotas/bases para un rendimiento IP65.
- Details A Han® 1A configuration that only consists of inserts (with or without strain relief, 09 10 000 5300) is an unenclosed connector according to IEC 61984.
Technical characteristics
- Limiting temperature -30 ... +85 °C
- Mating cycles ≥ 100
- Degree of protection acc. to IEC 60529 IP20
Material properties
- Material (insert) Poliamida (PA)
- Colour (insert) RAL 9005 (negro intenso)
- Material flammability class acc. to UL 94 V-0
- RoHS conforme
- ELV status conforme
- China RoHS e
- REACH Annex XVII substances No incluido
- REACH ANNEX XIV substances No incluido
- REACH SVHC substances No incluido
- California Proposition 65 substances No incluido
Specifications and approvals
- Specifications EN 45545-2 Protección contra incendios en vehículos ferroviarios
Commercial data
- Packaging size 1
- Net weight 1 g
- Country of origin Romania
- European customs tariff number 85366990
- GTIN 5713140481169
- eCl@ss 27440219 Module for industrial connectors (FO)
- ETIM EC000438
- UNSPSC 24.0 39121552
