Resumen de caracterísiticas
Juegos de conectores
Kit ciego
Hembra
Poliamida (PA)
Negro
Fundición de aluminio, Resistente a la corrosión
Grado de protección: IP67 / IP69
Detalles del producto
Identification
- Category Connector sets
- Series HARTING UIC
- Identification UIC IT
- Element Connector sets
- Specification Dummy kit
Version
- Gender Female
Technical characteristics
- Insulation resistance >107 Ω
- Tightening torque 5 Nm Fixing screws M6
- Limiting temperature -40 ... +90 °C
- Mating cycles ≥ 10,000
- Degree of protection acc. to IEC 60529 IP67 / IP69
Material properties
- Material (insert) Polyamide (PA)
- Colour (insert) Black
-
Material (hood/housing)
Aluminium die-castCorrosion resistant
- Surface (hood/housing) Powder-coated
- Colour (hood/housing) RAL 6005 (moos green)
- Material (seal) Silicone
- Material (locking) Stainless steel
- Material flammability class acc. to UL 94 V-0
- RoHS compliant
- ELV status compliant
- China RoHS e
- REACH Annex XVII substances Not contained
- REACH ANNEX XIV substances Not contained
- REACH SVHC substances Not contained
- California Proposition 65 substances Not contained
Specifications and approvals
-
Specifications
UIC 50558IRS 50558IEC 61373 Category 2IEC 60529
Commercial data
- Packaging size 1
- Net weight 0.657 kg
- Country of origin India
- European customs tariff number 85366990
- eCl@ss 27440115 Circular connector (set)
- ETIM EC002635
- UNSPSC 24.0 39121413
