Resumen de caracterísiticas
Conectores
Terminación de engaste
Hembra
Policarbonato (PC)
RAL 7032 (gris guijarro)
Corriente nominal: 400 A
Tamaño: 20
Contactos: 1
Sección de conductor: 95 ... 150 mm²
Detalles del producto
Identification
- Category Connectors
- Series HARTING ICC
- Element Inserts
Version
- Termination method Collegamento a crimpare
- Gender Femmina
- Size 20
- Number of contacts 1
- Details Ordinare i contatti separatamente
Technical characteristics
- Conductor cross-section 95 ... 150 mm²
- Rated current 400 A
- Rated voltage 600 V
- Pollution degree 3
- Insulation resistance >1010 Ω
- Limiting temperature -40 ... +125 °C
- Mating cycles ≥ 500
Material properties
- Material (insert) Policarbonato (PC)
- Colour (insert) RAL 7032 (grigio sabbia)
- Material flammability class acc. to UL 94 V-0
- RoHS Conforme
- ELV status Conforme
- China RoHS e
- REACH Annex XVII substances Non incluso
- REACH ANNEX XIV substances Non incluso
- REACH SVHC substances Non incluso
- California Proposition 65 substances Non incluso
Specifications and approvals
-
Specifications
IEC 61984IEC 60664-1
- Approvals CE
Commercial data
- Packaging size 1
- Net weight 0.01 g
- Country of origin India
- European customs tariff number 85366990
- GTIN 5713140491069
- eCl@ss 27440223 Contact insert for circular connectors
- UNSPSC 24.0 39121421
